Vortex Optics | Diamond 20-60x80 (Angled) | Spott

Previous Item Next Item
SKU: 100243
Vortex Optics | Diamond 20-60x80 (Angled) | Spott
R 12 000,00
Readily Available


Vortex Optics Diamond 20-60x80 (Angled) Spotting Riflescope


Born into the bloodline of our popular Diamondback family, this spotter delivers outstanding performance—clearly a superb choice when you need a heavyweight performer in a light, compact package. The Diamondback optics guarantee a bright image throughout the magnification range and, as true to all Diamondback optics, the rugged construction stands up to rough use in the field.

  • Magnification 20-60x
  • Objective Lens Diameter 80 mm
  • Linear Field of View 105-51 ft/1000 yds -
  • Angular Field of View 2-1 degrees
  • Close Focus 22 feet
  • Eye Relief 20-16.5 mm
  • Exit Pupil 4-1.3 mm
  • Length 14.8 inches
  • Weight 47.1 oz


A superb heavyweight performer in a light, compact package.


  • XR™ Fully Multi-Coated Proprietary coatings increase light transmission with multiple anti-reflective coatings on all air-to-glass surfaces.
  • Dielectric Coating Multi-layer prism coatings provide bright, clear, color-accurate images.
  • Porro Prism Valued for a rich depth of field, wide field of view, and three-dimensional image.
  • Waterproof O-ring seals prevent moisture, dust and debris from penetrating for reliable performance in all environments.
  • Fog proof Nitrogen gas purging prevents internal fogging over a wide range of temperatures.


  • Adjustable Eyecups Twist up and down for comfortable viewing with or without eyeglasses.
  • Built-in Sunshade Reduces glare and shields the objective lens from raindrops and snow.
  • Rotating Tripod Ring Allows rotation of the eyepiece to a sideways position, providing adjustable viewing angles.
  • Angled Body Design Valued for allowing an overall lower mounting height which maximizes stability in wind, offers greater comfort when glassing for extended periods, and permits the use of a smaller, lighter tripod.

Included in the Box

  • Eyepiece cap
  • Objective lens cover
  • View-through carry case
